OmniPulser GP — General-Purpose HV Pulse Generator
Overview
The OmniPulser GP is the general-purpose variant of the OmniPulser line — a high-voltage pulse generator configured for applications that don't belong to a specific domain. Plasma research, particle accelerator components, component testing, custom experimental setups: wherever a configurable high-voltage pulse source is needed, the GP is the starting point.
The parameter range is deliberately wide. Voltage from 5 kV to 100 kV, current from 50 A to 10 kA, PSU power to match — the right combination is determined by the application. Both unipolar and bipolar operation are available. A bipolar system can always be operated in unipolar mode.
Standard configurations
| Parameter | Options |
|---|---|
| Polarity | Unipolar / Bipolar |
| Peak Voltage | 5 / 10 / 20 / 30 / 40 / 100 kV |
| Peak Current | 50 / 100 / 250 / 500 A / 1 / 2 / 5 / 10 kA |
| PSU Power | 500 W / 4.5 kW / 9 kW / 18 kW |
Configurability and options
The GP's wide parameter envelope is the baseline. From there, the platform's full set of capabilities can be layered on depending on what the application requires: Arbitrary Sequencing for complex multi-pulse sequences, Adjustable Rise Times for applications sensitive to pulse edge speed, Real-Time Voltage and Current Measurement for verified pulse delivery, Remote API Control for automated or integrated setups, and more.
If your application requires sustained high-frequency continuous operation — running at high repetition rates over extended periods — the OmniPulser HF is the appropriate variant. It is built on the same platform with oil cooling to handle the thermal demands that come with continuous high-frequency use.
Available capabilities
- Constant Current
- Arbitrary Sequencing
- Adjustable Rise Times
- Steps Function
- Burst Mode
- Real-Time Voltage & Current Measurement
- External Trigger Input
- Remote API Control
- External Trigger Output
- External Signal Input
- Sawtooth/Ramp Generation
- Adjustable Overcurrent Protection
- Multi-Frequency Impedance Measurement
